ESCAM G24 H.265 3MP Full HD AI Identify Camera with Solar Panel PIR Alarm WiFi Camera Built-In Battery

ESCAM G24 H.265 3MP Full HD AI Identify Camera with Solar Panel PIR Alarm WiFi Camera Built-In Battery

5W solar panel with bracket, including 3m solar panel connection cable

300W HD pixel, clear picture quality

Standard H.265 video compression algorithm, to meet the narrow bandwidth network in the transmission of high-definition video

Support PIR alarm, APP message push, white light flashing, and alarm sound warning.

Support two-way voice intercom, echo cancellation, noise suppression

Intelligent night vision: 2 white lights, 2 infrared lights night vision lighting (night vision distance up to 20 meters)

Built-in rechargeable lithium battery 9000mAH, long battery life

Support 2.4G WiFi (IEEE802.11b/g/n)

Support cloud storage technology, support TF card storage (up to 128GB)

IP66 waterproof rating

Specifications:

Image Sensor

Sensor

1/2.9"color CMOS Sensor

Lens

M12, f: 2.8 mm, F2.2, 3-megapixel

Visual angle

H (horizontal) 96 degrees; V (vertical) 56 degrees; D (diagonal) 128 degrees

Minimum Illumination

0.01Lux

Audio

Input/Output

Two-way voice intercom available (built-in Microphone and speaker)

Audio Compressing Method

AAC

Video

Video Compressing Method

H.265

Lighting Frequency

50 Hz，60 Hz

Image Frame Rate

15 fps

Maximum Image Resolution

2304*1296

Light Source for Night Vision

Mid-power infrared lamp (850nm in wavelength) / dual-source white-light source with an irradiation distance of 20m

Network

Wireless Network

2.4G Wi-Fi (IEEE802.11b/g/n), built-in antenna

Protocols Supported

TCP/IP, UDP/IP, DHCP, RTMP, MUTP

IP Address Supported

Dynamic IP address supported

Pan-tilt

rotation angle

H (horizontal) 355 degrees; V (vertical) 90 degrees

AI

Intelligent Features

Human contour detection, activity zone, vehicle detection, pet snapshot, and package inspection

Alarm Notification

Alarm Methods

Alarm push by mobile APP, white light  flashing, and alarm sound

Wake-up

Wake-up Method

PIR body induction wake-up, and remote wake-up

Video Recording

Recording Method

Alarm-triggered recording, and manual recording

Video Storage

Cloud storage, local Micro SD card, and mobile phone memory

Indicator Lamps

LED Indicator

RGB tri-color lamp indicating the status of power/network signal/functionality

Battery

Capacity

9000mAh

Removability

Unremovable

Charging Voltage

DV 5V+-5% 1.5A

Charge Time

Within 15 hours

Power Consumption

Standby Power Consumption

1.68 mW

Power Consumption of Daytime Operation

0.88 W

Power Consumption of Operation at Night

2.23 W

Interfaces

Power Supply

1 Micro USB interface

TF Card

1 TF card (up to 128GB supported)

Keys

1 reboot key and 1 on/off key

Installation Method

Installation Method

Magnet and 1/4 universal screw holes

Environment

Dustproof and waterproof

IP66

Operating Environment

 -10 ℃-45 ℃

Storage Environment

 -20 ℃-60 ℃
