Carlinkit SDM660 Tbox UHD Wireless CarPlay / Android Auto Adapter w. HDMI, USB-C, USB, TF Card Slot

Carlinkit SDM660 Tbox UHD Wireless CarPlay / Android Auto Adapter with HDMI, USB-C, USB, TF Card Slot - 8GB/128GB, OS: Android 13, Bluetooth 5.0

This product expands the open Android system platform through the car USB interface, supports free installation of APP to achieve richer audio-visual entertainment and navigation functions, supports 4G/GPS/Bluetooth/telephone functions, and supports mobile phone Internet access to realize wireless CarPlay and wireless Android Auto function. Output high-definition images through the HDMI port, connect to other high-definition displays, and switch between split-screen displays without interfering with each other or affecting driving, thereby realizing the fun of sharing high-definition images.

Android Link Box facilitates seamless connections to open Android systems, enabling wireless CarPlay and Android Auto connectivity

Enjoy online HD multimedia entertainment with support for streaming high-definition videos and media content

Effortlessly connect to other high-definition displays for crisp and clear output imagery

Experience hassle-free multitasking with split-screen display, allowing for simultaneous usage without interference

Retain original car functionalities such as buttons and knobs for intuitive and immediate operation

Switch between original car CarPlay and Android Auto channels as needed, ensuring versatile compatibility

Specification:

Power input: 5V±0.2V 2A

Product power consumption: 6W

WiFi frequency: 802.11a/b/g/n/ac, 2.4G+5G

CPU: Qualcomm SDM660, 4xKryo Gold 2.2(or 2.4)GHz + 4xKryo Silver 1.8GHz

GPU: A512 650MHz

System: open Android system

Memory: 8GB running memory + 128GB body memory

WiFi module: WCN3980

MFI: MFI 3959

Bluetooth version: 5.0 BR/EDR/BLE

Product material: ABS

Compatible car units: models with original car’s own wired CarPlay/wired Android Auto

Resolution: adaptive (maintain original protocol resolution)

Language: Multiple languages ​​around the world, (Arabic, Chinese, English, French)

Ports: LED indicator, Type-C female port, TF card holder, USB female port, SIM card holder, HDMI interface

Product size: 90x84.9x17.1mm

Cable: USB-A to USB-C*1, USB-C to USB-C*1, Length=300mm

HD Adapter*1, Length=170mm

TF card supports expansion: 512GB

Wireless CarPlay: for iPhone 6 and above/for iOS 10.0 and above

Wireless Android Auto: Android phones running Android 11.0 and above

Version: Eurasian EAU (Asia, European countries)

Cellular network format: EAU SIM/Nano SIM/LTE-FDD B1/2/3/4/5/7/8/20/28/LTE-TDD B38/40/41/WCDMA B1/2/3/5/8 /GSM/EDGE 850/900/1800/1900MHz

Product Certificate:

Certification number: AT18300RC105486

Rosh certification

Patent number: ZL202230224097.X

Design patent

FCC ID:2AYC2-AITBOX

FCC certification

Certificate ID:189005

Bluetooth membership certification

Certification number: R210-181448

TELEC certification

Certification number: AT18220WC102475

CMIIT ID: 2022AP9009

CE certification

SRRC certification

Certification ID: CCAH22LP9040T2

NCC certification

Note：

Incorrect card insertion may cause damage to the card slot

Under normal circumstances, the Android Auto function is not supported in mainland China

Insert the card pin and hold it for about 2-3 seconds to switch to CarPlay (default) or Android Auto mode
